Wear Protection Metal Carbide Powder Chromium Carbide Powder 325-5.5um

Name: Wear Protection Metal Carbide Powder Chromium Carbide Powder 32555um
Brand: BODA
Price: 18.0 USD

Wholesale Wear Protection Metal Carbide Powder Chromium Carbide Powder 325-5.5um from china suppliers

Brand Name : BODA

Model Number : BD-30101 BD-30102 BD-30103 BD-30104 BD-30105

Certification : ISO9001:2015,ISO14001

Place of Origin : China

MOQ : 50kg

Price : US$18.0/kg-$26.0/kg EX-WORK

Payment Terms : T/T

Supply Ability : 20-30 tons per month

Delivery Time : 5-8 working days

Packaging Details : 50kg per drum or 100kg per drum

Color : dark gray

Shape : irregular

Chemicals : Ct 12.5% max Cf 0.5% max Cr 85.5%min

Size : -11um ,140-325mesh 325-5.5um

Item : Chromium Carbide Powder

Contact Now

Chromium Carbide Powder Used As An Additive In Cutting Tools Made Of Cemented Carbides Also As Surface Treatment

Chemical Composition:

Grade	Ct	Cf	Cr	Fe	Si	O	Al	P	S
BD-30101	≥12.75	≤ 0.3	≥85.5	≤0.5	≤0.15	≤0.5	≤0.15	≤0.02	≤0.035
BD-30102	≥12.75	≤ 0.3	≥85.5	≤0.5	≤0.15	≤0.5	≤0.15	≤0.02	≤0.035
BD-30103	≥12.75	≤ 0.3	≥85.5	≤0.5	≤0.15	≤0.5	≤0.15	≤0.02	≤0.035
BD-30104	≥12.75	≤ 0.3	≥85.5	≤0.5	≤0.15	≤0.5	≤0.15	≤0.02	≤0.035
BD-30105	≥12.75	≤ 0.3	≥85.5	≤0.5	≤0.15	≤0.5	≤0.15	≤0.02	≤0.035

Specification :

Grade	Average Particle Size
BD-30101	≤11um
BD-30102	2-3um
BD-30103	≤2um
BD-30104	140-325mesh
BD-30105	325-5um

Chromium carbide is useful in the surface treatment of metal components. Chromium carbide is used to coat the surface of another metal in a technique known as thermal spraying. Cr₃C₂ powder is mixed with solid nickel-chromium. This mixture is then heated to very high temperatures and sprayed onto the object being coated where it forms a protective layer. This layer is essentially its own metal matrix composite, consisting of hard ceramic Cr₃C₂ particles embedded in a nickel-chromium matrix. The matrix itself contributes to the corrosion resistance of the coating because both nickel and chromium are corrosion resistant in their metallic form. After over spraying the coating, the coated part must run through a diffusion heat treatment to reach the best results in matter of coupling strength to the base metal and also in matter of hardness.

Another technique utilizes chromium carbide in the form of overlay plates. These are prefabricated chromium carbide-coated steel plates, which are meant to be welded onto existing structures or machinery in order to improve performance.

Chromium carbide is used as an additive in cutting tools made of cemented carbides, in order to improve hardness by preventing the growth of large grains.^[8] The primary constituent in most extremely hard cutting tools is tungsten carbide. The tungsten carbide is combined with other carbides such as titanium carbide, niobium carbide, and chromium carbide and sintered together with a cobalt matrix. Cr₃C₂ prevents large grains from forming in the composite, which results in a fine-grained structure of superior hardness.

Undesired formation of chromium carbides in stainless steel and other alloys can lead to intergranular corrosion.
